Machine tap M25x2 DIN 374 C HSSE
0000007284
Thread size: M25x275 sizes of this tap
M3x0,35M3,5x0,35M4x0,5M5x0,5M6x0,75M8x0,75M8x1M10x0,5M10x0,75M10x1M10x1,25M11x1M12x1M12x1,25M12x1,5M14x1M14x1,25M14x1,5M15x1M15x1,5M16x0,75M16x1M16x1,5M16x1,75M17x0,75M17x1M18x1M18x1,25M18x1,5M18x2M19x1M20x1M20x1,25M20x1,5M20x2M22x1M22x1,5M22x2M23x1,25M24x1M24x1,5M24x2M25x1M25x1,5M25x2M27x1M27x1,5M27x2M28x1M28x1,5M28x2M30x1M30x1,5M30x2M32x1,5M32x2M33x1,5M33x2M34x1,5M35x1,5M36x1,5M36x2M36x3M38x1,5M39x1M39x1,5M40x1,5M42x2M48x1,5M48x2M48x3M50x1,5M52x1,5M52x3M56x3
€74.45 tax inc.
Net price: €60.53
Description
Material HSSE
Thread size M25x2
ChamferC (2–3) threads
Standard DIN 374
Technical data for the M25x2 HSSE INOX general-purpose machine tap
| Technical Data | |
|---|---|
| Nominal Diameter d1 | M25x2 |
| Thread Pitch P | 2 mm |
| Overall Length l1 | 140 mm |
| Flute Length l2 | 27 mm |
| Shank Diameter d2 | 18 mm |
| Square Drive Size a | 14.5 mm |
| Tap Drill Diameter | 23 mm |
| Chamfer | C (2÷3) P |
| Thread tolerance | 6H |
Where chips remain in a straight-flute tap
The flute holds the chips until the tap is reversed out
The straight flute runs parallel to the tap axis. There is no helix to carry chips upward. The chamfer cutting edges are not ground at an angle, so they do not push chips downward. Short chips break into fragments and remain in the flute, next to the cutting edges that produced them. They leave the hole only when the tap is backed out. The M25x2 tap has a reduced shank to DIN 374: diameter 18 mm, square size 14.5 mm.
1
Straight flute – chips remain in the flute, next to the cutting edges that produced them.
2
Chamfer C: 2–3 incomplete threads on the tapered lead.
3
The tap rotates clockwise to cut a right-hand thread.
4
Individual fragments exit at the top, onto the workpiece surface.
5
A few fragments fall below the tip and exit through the bottom of the hole.
6
Feed 2 mm/rev, equal to the pitch of the M25x2 thread.
M25x2 INOX machine tap – for CNC machining
In this line, the manufacturer offers the M25x2 INOX machine tap with optimized cutting geometry for fine threads with a pitch of 2 mm. The tool meets the requirements of DIN 374 and provides thread tolerance class 6H required in series production of mechanical and precision components. Its HSSE steel construction with 5% cobalt guarantees a hardness of 66 HRC and resistance to temperatures up to 650°C in the cutting zone. Form C with straight flutes provides general-purpose capability for through holes and blind holes in stainless and structural steels.
Advantages of the M25x2 INOX tap
- Compatibility with ER32 holders collets and synchronized tapping chucks for CNC machining centers with automatic tool change
- Durability increased by the addition of cobalt in HSSE steel extends cutting edge life by 40-60% compared with standard HSS taps
- Material versatility covering austenitic stainless steels 304 and 316, structural steels up to 800 MPa and nonferrous metals such as aluminum and brass
- Precision to tolerance class 6H meeting the requirements of series production of mechanical and pneumatic components with tight fit tolerances
- Conforms to DIN 374 for fine threads ensures standardized shank dimensions and interchangeability with tools from European manufacturers
- M25x2 general-purpose machine tap with form C ensures proper chip evacuation in through holes and blind holes without the risk of jamming
The M25x2 HSSE machine tap is used in steel structures, industrial welding, and the production of industrial automation components. The M25x2 machine tap for through and blind holes is compatible with automatic tool change systems. The tap drill diameter for the M25x2 thread is 23 mm.
Cutting data for the M25x2 HSSE INOX general-purpose machine tap
| Material | Cutting speed Vc [m/min] | Spindle speed n [rpm] | Feed f [mm/min] |
|---|---|---|---|
| PSteel | 5-20 | 64-255 | 128-510 |
| MStainless steel / INOX | 5-10 | 64-127 | 128-254 |
| KCast iron | 5-15 | 64-191 | 128-382 |
| NAluminum | 10-25 | 127-318 | 254-636 |
Thread preparation M25x2
1 Spot drilling
NC spotting drill 90°
2 Drilling
Ø 23 mm
3 Tapping
M25x2
✓ Done!
Tolerance 6H
Standard: DIN 374 | Chamfer: C (straight) | Application: general-purpose (through and blind holes)
Tolerance 6H — metric thread tolerance classes
| Class | Accuracy | Application | Status |
|---|---|---|---|
| 4H / 4g | High | Precision connections, hydraulics | — |
| 6H / 6g | Standard | Machine building, general-purpose | SELECTED |
| 7H / 8g | Low | Large clearance, easy assembly | — |
6H = internal thread (nut, hole) | 6g = external thread (screw)
Frequently asked questions
The M25x2 HSSE tap is suitable for austenitic stainless steels 304 and 316, structural steels up to 800 MPa, ductile cast iron, and aluminum and brass alloys. It is not recommended for hardened steels above 45 HRC.
The nominal tap drill diameter for the M25x2 thread is 23 mm. The hole tolerance range should be 22.9–23.1 mm. A hole at the lower tolerance limit produces a fuller thread profile, while one at the upper limit reduces tapping torque.
The M25x2 tap works with ER32 holders and tapping chucks with axial compensation. Synchronized heads with automatic tool change capability are recommended for CNC machines.
