Description
| Technical Data | |
|---|---|
| ISO designation | MVQNR 25x25 16 |
| Shank height (h) | 25 mm |
| Shank width (b) | 25 mm |
| Overall length (L) | 150 mm |
| Functional overhang (f) | 25 mm |
| Entering angle (κr) | 107.5° |
| Clearance angle | 0° (negative) |
| Clamping system | ISO — combination (M) |
| Insert type | VNMG 1604rr |
| Cutting direction | R — right-hand |
| Manufacturer | Varel |
Professional 25×25 mm indexable turning tool for a VNMG insert
Turning tool MVQNR 25x25 16 is a professional turning tool designed for external turning on conventional and CNC lathes. The shank with a cross section of 25×25 mm and a length of 150 mm provides the rigidity required for industrial machining. The geometry with an entering angle of 107.5° enables longitudinal turning with facing.
The combination clamping system (M) ensures maximum clamping rigidity and quick replacement of the VNMG 1604rr insert. The negative geometry of the 35° rhombic insert with 4 cutting edges is suitable for roughing and medium machining, providing high cutting edge strength and cost efficiency thanks to its double-sided design. The tool is compatible with VNMG 16 inserts in various carbide grades — select the grade to match the workpiece material.
Cutting operations:
| ▸ | Longitudinal turning — the 107.5° angle provides stable cutting along the workpiece axis with light facing |
| ▸ | Roughing and medium machining of steel and cast iron — negative VNMG geometry provides maximum cutting edge strength and 2× as many edges |
| ▸ | Machining shafts and bushings — a general-purpose tool for external turning of rotational parts |
| ▸ | Taper turning — machining tapered surfaces on CNC and conventional lathes |
| ▸ | CNC production runs — quick insert replacement and repeatable positioning |
Package contents for MVQNR 25x25 16
Package contents:
| ✓ | Tool body MVQNR 25x25 16 | 1 pcs |
| ✓ | Combination clamp (clamp + pin) | 1 pcs |
| ✓ | Hex key for insert replacement | 1 pcs |
| ✗ | VNMG 1604rr cutting insert (sold separately) | — |
VNMG 1604rr
The cutting insert is not included in the set — must be purchased separately. VNMG insert. Negative geometry means that the insert is double-sided and has 4 cutting edges, providing maximum cutting edge strength and cost efficiency.
Select the insert grade to match the workpiece material: P (structural steels), M (stainless steel), K (cast iron), N (aluminum). You can find compatible inserts in the section "Related products" below.
Instructions for the combination clamping system (M)
Loosen the clamping screw 2-3 turns
Remove chips and debris
Fit onto the pin and press down
Torque 2.0–3.5 Nm
Important: Do not exceed the recommended tightening torque — this may damage the thread in the seat or crack the insert.
Checks before starting work:
| ▸ | Tool overhang — do not exceed 1.5× the shank height without support |
| ▸ | Cutting edge height — set the cutting edge at spindle center height (±0.05 mm) |
| ▸ | Insert seat condition — check that the contact surface is not damaged or worn |
| ▸ | Secure clamping — the insert must have no play in the seat |
| ▸ | Indexing — when an edge wears out, rotate the insert to a fresh edge (4 edges in total) |
Note: Use coolant during machining — it extends insert life and improves surface finish. When machining without coolant, reduce the cutting parameters by 20–30%.
This tool accepts inserts VNMG 1604rr in any carbide grade. Select the grade to match the workpiece material: P (steels), M (stainless steel), K (cast iron), N (aluminum). You can find compatible inserts in the "Related products" section below.
The entering angle of 107.5° provides stable longitudinal turning with light facing. The most popular angle for general-purpose machining on CNC and conventional lathes.
The VNMG insert has negative geometry (clearance angle 0°), which means it is double-sided with 4 cutting edges. When one edge wears out, rotate or flip the insert to use the next edge — this significantly reduces tooling cost per part.
