Description
| Technical data | |
|---|---|
| ISO designation | TCZNN 20x20 K12 |
| Shank height (h) | 20 mm |
| Shank width (b) | 20 mm |
| Overall length (L) | 125 mm |
| Functional overhang (f) | 10 mm |
| Entering angle (κr) | 40° |
| Clearance angle | 0° (negative) |
| Clamping system | ISO — top and through-hole clamping (T) |
| Insert type | CNMG 1204rr |
| Cutting direction | N — neutral (both directions) |
| Manufacturer | Smoxh |
Indexable turning tool 20×20 mm for a CNMG insert
Turning tool TCZNN 20x20 K12 is an indexable turning tool designed for external turning on conventional and CNC lathes. The shank, with a cross section of 20×20 mm and a length of 125 mm, provides the rigidity required for industrial machining. The geometry with an entering angle of 40° allows simultaneous longitudinal turning and angled facing.
In the top-and-hole clamping system (T), the clamp secures the CNMG 1204rr insert from above and through its hole. The negative geometry of the 80° rhombic insert with 4 cutting edges is suitable for roughing and medium machining, providing high cutting edge strength and cost efficiency thanks to its double-sided design. The turning tool is compatible with CNMG 12 inserts in various carbide grades — select the grade to match the workpiece material.
What the individual letters in the ISO designation mean





Cutting operations:
| ▸ | Longitudinal turning with facing — the 40° angle allows simultaneous cutting along the axis and facing |
| ▸ | Roughing and medium machining — negative CNMG geometry provides a stronger cutting edge |
| ▸ | Chamfering and external tapers — angled cutting edge for chamfers and tapers |
| ▸ | Turning steps and shoulders — machining cylindrical surfaces with changes in diameter |
| ▸ | CNC production runs — quick insert replacement and repeatable positioning |
Package contents for TCZNN 20x20 K12
Package contents:
| ✓ | Tool body TCZNN 20x20 K12 | 1 pcs |
| ✓ | Top clamp with screw | 1 pcs |
| ✓ | Hex key for insert replacement | 1 pcs |
| ✗ | CNMG 1204rr cutting insert (sold separately) | — |
CNMG 1204rr
The cutting insert is not included in the set — must be purchased separately. CNMG insert. Negative geometry means that the insert is double-sided and has 4 cutting edges, providing a stronger cutting edge and twice as many edges as a single-sided insert.
Select the insert grade to match the workpiece material: P (structural steels), M (stainless steel), K (cast iron), N (aluminum). You can find compatible inserts in the section "Related products" below.
Instructions for top and through-hole clamping (T)
Loosen the clamp screw 2-3 turns
Remove chips and debris
Position in the seat under the clamp
Torque 3.0–4.5 Nm
Important: Do not exceed the recommended tightening torque — this may damage the thread in the seat or crack the insert.
Checks before starting work:
| ▸ | Tool overhang — do not exceed 1.5× the shank height without support |
| ▸ | Cutting edge height — set the cutting edge at spindle centerline height |
| ▸ | Insert seat condition — check that the contact surface is not damaged or worn |
| ▸ | Secure clamping — the insert must have no play in the seat |
| ▸ | Indexing — when an edge wears out, rotate the insert to a fresh edge (4 edges in total) |
Note: Use coolant during machining — it extends insert life and improves surface finish. When machining without coolant, reduce the cutting parameters by 20–30%.
This tool accepts inserts CNMG 1204rr in any carbide grade. Select the grade to match the workpiece material: P (steels), M (stainless steel), K (cast iron), N (aluminum). You can find compatible inserts in the "Related products" section below.
The entering angle of 40° allows simultaneous longitudinal turning and facing. Suitable for machining chamfers, tapers and transitions between diameters.
The CNMG insert has negative geometry (clearance angle 0°), which means that it is double-sided with 4 cutting edges. When one edge wears out, rotate or flip the insert to use the next edge — this significantly reduces tooling cost per part.
