Description
Technical specifications of the S16 SSSCR 09 folding knife
| Technical data | |
|---|---|
| DCON handle width | 16 mm |
| Width H | 14.8 mm |
| Overall length L | 170 mm |
| Working height f | 11 mm |
| Minimum bore Dmin | 20 mm |
| Carbide insert matching | Carbide insert SCMT 09T3 |
Turning tool s16 SSSCR 09 SCMT 09T3rr boring bar
Turning tool S16 SSSCR 09 is a professional turning tool boring bar for internal turning, designed for CCMT 09T3rr inserts (rr - corner radius). The 45-degree angle defines the shaping possibilities: 45-degree chamfer, 45-degree undercut, profiling and safe access to the bottom of the hole. Right-hand execution (R) means feed from right to left with standard spindle direction.
Turning tool S16 SSSCR 09 works with CCMT 09T3 inserts with a C-shape (80-degree corner angle) and a C-angle of 7 degrees. The center bolt fastening ensures repeatable fixation and quick replacement, and the fi 16 mm shank guarantees rigidity. Rule of thumb for overhang selection: maximum overhang length = 4 x shank diameter; example: fi 16 mm is 64 mm. CCMT 09T carbide insert mounting is available for steel, stainless steel, cast iron, aluminum and CBN tipped inserts.
User benefits:
- 45-degree bevel angle - allows 45-degree chamfers and undercuts and machining with limited access.
- Shank fi 16 mm - stable tool guidance while maintaining the recommended extension length of up to 4 x shank diameter.
- Center screw attachment - repeatable edge positioning and shorter changeover time.
- CCMT 09T3 standard - wide selection of rr radii for required roughness and depth of cut.
Turning tool S16 SSSCR 09 will perform well in CNC and conventional lathes, providing repeatable quality in precision internal operations in unit and batch production.
