Description
| Technical Specifications | |
|---|---|
| Shank width D | 20 mm |
| Width H | 18.3 mm |
| Minimum bore diameter D | 25 mm |
| Total length L | 170 mm |
| Length of Working Part L | 38 mm |
| Maximum depth of cut Tmax | 13 mm |
Turning tool AIKT-K-R-20-3-T7 Akko is a precision tool designed for internal turning, grooving and cutting. Its design ensures stable bore operation and repeatable machining quality, which is crucial in manufacturing applications requiring high accuracy.
The 20 x 18.3 mm shank guarantees adequate rigidity and resistance to vibration, which is important for deeper operations. Insert clamping is done with a K-type clamping screw, which allows for quick and secure installation. The tool works with MGMN 300 inserts, which have a width of 3.0 mm, a thickness in the range of 2.38-3.18 mm and a corner radius of 0.2-0.4 mm. This geometry allows for clean grooves and precise cutting in materials such as steel, cast iron and stainless steel.
- Precision cutting - the MGMN 300 insert enables accurate separation of parts from bars and blanks.
- External grooving - provides the ability to make straight grooves with a width of 3.0 mm.
- Face grooving - allows you to create channels from the face of the workpiece in through-holes and blind holes.
- Stable shank - dimension 20 x 18.3 mm reduces vibration and extends the life of the insert during operation.
Turning tool AIKT-K-R-20-3-T7 Akko with MGMN 300 insert is designed for workshops and factories that expect reliability and high quality in grooving and cutting operations.
