CROSS SECTION 16×16 mm
LENGTH 100 mm
INSERT VCMT 1103rr
ANGLE κr 72.5°
Technical specifications of the SVVCN 16X16 H11 turning tool
| Technical data | |
|---|---|
| ISO designation | SVVCN 16X16 H11 |
| Shank height (h) | 16 mm |
| Shank width (b) | 16 mm |
| Overall length (L) | 100 mm |
| Functional overhang (f) | 8 mm |
| Entering angle (κr) | 72.5° |
| Clearance angle | 7° (pos.) |
| Clamping system | ISO — center screw (S) |
| Insert type | VCMT 1103rr |
| Cutting direction | N — neutral (both directions) |
| Manufacturer | Smoxh |
SVVCN 16X16 H11 turning tool – for longitudinal turning and profiling
Indexable turning tool 16×16 mm for a VCMT insert
Turning tool SVVCN 16X16 H11 is an indexable turning tool designed for external turning on conventional and CNC lathes. The shank with a 16×16 mm cross section and a length of 100 mm provides the rigidity required for industrial machining. The geometry with a 72.5° entering angle enables longitudinal turning and profiling in both feed directions, with good access to the machined surface.
In the central screw clamping system (S), the screw clamps the VCMT 1103rr insert through its hole, so replacement requires loosening just one screw. The positive geometry of the 35° rhombic insert with 2 cutting edges is well suited to finishing, ensuring low cutting forces and a smooth machined surface. The tool is compatible with VCMT 11 inserts in various carbide grades — select the grade to match the workpiece material.
Decoding the SVVCN designation of the SVVCN 16X16 H11 turning tool
What the individual letters in the ISO designation mean
Decoding the designation SVVCN
S
CLAMPING
Center screw (S)
The screw secures the insert through its center hole
V
INSERT SHAPE
35° rhombus 35°
VCMT insert — positive, single-sided, 2 edges
V
ENTERING ANGLE
κr = 72.5°
Longitudinal turning — angled 35° rhombic insert
C
CLEARANCE ANGLE
α = 7° (pos.)
Positive geometry — low cutting forces, finishing and medium machining
N
DIRECTION
Neutral (N)
Operation in both directions — neutral tool
Shank: 16×16 mm · Insert: VCMT 1103rr
Typical applications of the SVVCN 16X16 H11 turning tool
Cutting operations:
| ▸ | Longitudinal turning with profiling — the 72.5° angle provides good access to the workpiece profile |
| ▸ | Medium machining and finishing of steel and cast iron — positive VCMT geometry ensures low cutting forces |
| ▸ | External taper turning — machining tapered and contoured surfaces |
| ▸ | Profiling and recess machining — the neutral insert orientation allows angled entry into recesses; the entry angle is limited by the insert shape |
| ▸ | CNC production runs — quick insert replacement and repeatability |
Included
SVVCN 16X16 H11 package contents
Package contents:
| ✓ | Tool body SVVCN 16X16 H11 | 1 pcs |
| ✓ | Center screw for clamping the insert | 1 pcs |
| ✓ | Hex key for insert replacement | 1 pcs |
| ✗ | VCMT 1103rr cutting insert (sold separately) | — |
Compatible VCMT 1103rr insert
VCMT 1103rr
The cutting insert is not included in the set — must be purchased separately. VCMT insert. Positive geometry means that the insert is single-sided and has 2 cutting edges, providing low cutting forces and good surface quality.
Select the insert grade to match the workpiece material: P (structural steels), M (stainless steel), K (cast iron), N (aluminum). You can find compatible inserts in the section "Related products" below.
Insert installation and replacement for the SVVCN 16X16 H11 turning tool
Instructions for the center screw clamping system (S)
Insert replacement procedure step by step
1 Unscrew the screw
Unscrew the center screw 2-3 turns
2 Clean the insert seat
Remove chips and debris
3 Install the insert
Position in the seat
4 Tighten the screw
Torque 2.0–3.5 Nm
Important: Do not exceed the recommended tightening torque — this may damage the thread in the seat or crack the insert.
Checks before starting work:
| ▸ | Tool overhang — do not exceed 1.5× the shank height without support |
| ▸ | Cutting edge height — set the cutting edge at spindle centerline height |
| ▸ | Insert seat condition — check that the contact surface is not damaged or worn |
| ▸ | Secure clamping — the insert must have no play in the seat |
| ▸ | Indexing — when an edge wears out, rotate the insert to a fresh edge (2 edges in total) |
Note: Use coolant during machining — it extends insert life and improves surface finish. When machining without coolant, reduce the cutting parameters by 20–30%.
Frequently asked questions — SVVCN 16X16 H11
This tool accepts inserts VCMT 1103rr in any carbide grade. Select the grade to match the workpiece material: P (steels), M (stainless steel), K (cast iron), N (aluminum). You can find compatible inserts in the "Related products" section below.
The 72.5° entering angle provides good access to the workpiece profile. It is suitable for longitudinal turning, contour profiling, and recess machining.
The VCMT insert has positive geometry (clearance angle 7°), which means it is single-sided with 2 cutting edges. When one edge wears out, rotate the insert to a fresh edge.
Product accessories
Carbide insert VCMT 110304 H6310 Horn
Reference: 0000007916 In stock > 10 items
€4.74
€5.83 brutto
Carbide insert VCMT 110308 H6310 Horn
Reference: 0000012244 In stock > 10 items
€3.68
€4.53 brutto
