Description
CROSS SECTION 25×25 mm
LENGTH 125 mm
INSERT RCMT 1003rr
ANGLE κr variable
Technical specifications of the SRXCR 25x25 10 turning tool
| Technical data | |
|---|---|
| ISO designation | SRXCR 25x25 10 |
| Shank height (h) | 25 mm |
| Shank width (b) | 25 mm |
| Overall length (L) | 125 mm |
| Functional overhang (f) | 50 mm |
| Entering angle (κr) | variable, depends on the depth of cut |
| Clearance angle | 7° (pos.) |
| Clamping system | ISO — center screw (S) |
| Insert type | RCMT 1003rr |
| Cutting direction | R — right-hand (L version available) |
| Manufacturer | Smoxh |
Turning tool SRXCR 25x25 10 – for longitudinal turning with light facing
25×25 mm indexable turning tool for an RCMT insert
Turning tool SRXCR 25x25 10 is an indexable turning tool designed for external turning on conventional and CNC lathes. The shank with a 25×25 mm cross section and a length of 125 mm provides the rigidity required for industrial machining. A round insert has no fixed entering angle: κr increases with the depth of cut. The tool performs longitudinal turning, facing, and contouring of gentle profiles.
In the central screw clamping system (S), a screw clamps the RCMT 1003rr insert through its hole, so replacement requires loosening only one screw. The positive geometry of the round insert with a continuous cutting edge is suitable for finishing, providing low cutting forces and a smooth machined surface. The tool is compatible with RCMT 10 inserts in various carbide grades — select the grade to match the workpiece material.
Decoding the SRXCR designation of the SRXCR 25x25 10 turning tool
What the individual letters in the ISO designation mean
Decoding the designation SRXCR
S
CLAMPING
Center screw (S)
The screw secures the insert through its center hole
R
INSERT SHAPE
Round 360°
RCMT insert — contouring and smoothing profiles
X
ENTERING ANGLE
κr — variable
External turning tool with a round insert; the entering angle depends on the point of contact with the material.
C
CLEARANCE ANGLE
α = 7° (pos.)
Positive geometry — low cutting forces, finishing and medium machining
R
DIRECTION
Right-hand (R)
Feed to the left — from the tailstock toward the spindle
Shank: 25×25 mm · Insert: RCMT 1003rr
Typical applications of the SRXCR 25x25 10 turning tool
Cutting operations:
| ▸ | Longitudinal turning — the round insert cuts along the axis and faces the end |
| ▸ | Medium machining and finishing of steel and cast iron — positive RCMT geometry provides low cutting forces and a smooth surface |
| ▸ | Machining shafts and bushings — a general-purpose tool for external turning of rotational parts |
| ▸ | Taper turning — machining tapered surfaces on CNC and conventional lathes |
| ▸ | CNC production runs — quick insert replacement and repeatable positioning |
Included
Package contents for SRXCR 25x25 10
Package contents:
| ✓ | Tool body SRXCR 25x25 10 | 1 pcs |
| ✓ | Center screw for clamping the insert | 1 pcs |
| ✓ | Hex key for insert replacement | 1 pcs |
| ✗ | RCMT 1003rr cutting insert (sold separately) | — |
Compatible RCMT 1003rr insert
RCMT 1003rr
The cutting insert is not included in the set — must be purchased separately. RCMT insert. Positive geometry means that the insert is single-sided and has a continuous cutting edge, providing low cutting forces and good surface quality.
Select the insert grade to match the workpiece material: P (structural steels), M (stainless steel), K (cast iron), N (aluminum). You can find compatible inserts in the section "Related products" below.
Insert installation and replacement for the SRXCR 25x25 10 turning tool
Instructions for the center screw clamping system (S)
Insert replacement procedure step by step
1 Unscrew the screw
Unscrew the center screw 2-3 turns
2 Clean the insert seat
Remove chips and debris
3 Install the insert
Position in the seat
4 Tighten the screw
Torque 0.8–1.5 Nm
Important: Do not exceed the recommended tightening torque — this may damage the thread in the seat or crack the insert.
Checks before starting work:
| ▸ | Tool overhang — do not exceed 1.5× the shank height without support |
| ▸ | Cutting edge height — set the cutting edge at spindle centerline height |
| ▸ | Insert seat condition — check that the contact surface is not damaged or worn |
| ▸ | Secure clamping — the insert must have no play in the seat |
Note: Use coolant during machining — it extends insert life and improves surface finish. When machining without coolant, reduce the cutting parameters by 20–30%.
Frequently asked questions — SRXCR 25x25 10
This tool accepts inserts RCMT 1003rr in any carbide grade. Select the grade to match the workpiece material: P (steels), M (stainless steel), K (cast iron), N (aluminum). You can find compatible inserts in the "Related products" section below.
A round insert has no fixed entering angle: κr increases with the depth of cut. The tool is used for longitudinal turning, facing, and profiling gentle transitions between diameters.
Select the grade according to the ISO material group: P (non-alloy and alloy steels), M (stainless and heat-resistant steel), K (gray and ductile cast iron), N (aluminum and non-ferrous metals). Grades labeled "universal" are suitable for most applications.
