Description
CROSS SECTION 10×10 mm
LENGTH 70 mm
INSERT CCMT 0602rr
ANGLE κr 50°
Technical specifications of the SCMCN 10x10 E06 turning tool
| Technical data | |
|---|---|
| ISO designation | SCMCN 10x10 E06 |
| Shank height (h) | 10 mm |
| Shank width (b) | 10 mm |
| Overall length (L) | 70 mm |
| Functional overhang (f) | 5 mm |
| Entering angle (κr) | 50° |
| Clearance angle | 7° (pos.) |
| Clamping system | ISO — center screw (S) |
| Insert type | CCMT 0602rr |
| Cutting direction | N — neutral (both directions) |
| Manufacturer | Varel |
SCMCN 10x10 E06 turning tool – for longitudinal turning and facing
10×10 mm indexable turning tool for a CCMT insert
Turning tool SCMCN 10x10 E06 is an indexable turning tool designed for external turning on conventional and CNC lathes. The shank, with a cross section of 10×10 mm and a length of 70 mm, provides the rigidity required for industrial machining. The geometry with an entering angle of 50° allows simultaneous longitudinal turning and angled facing.
In the central screw clamping system (S), the screw secures the CCMT 0602rr insert through its hole, so only one screw needs to be loosened for replacement. The positive geometry of the 80° diamond insert with 2 cutting edges is well suited to finishing, providing low cutting forces and a smooth machined surface. The turning tool is compatible with CCMT 06 inserts in various carbide grades — select the grade to match the workpiece material.
Decoding the SCMCN designation of the SCMCN 10x10 E06 turning tool
What the individual letters in the ISO designation mean
Decoding the designation SCMCN
S
CLAMPING
Center screw (S)
The screw secures the insert through its center hole
C
INSERT SHAPE
80° rhombus 80°
CCMT insert — positive, single-sided, 2 cutting edges
M
ENTERING ANGLE
κr = 50°
Longitudinal turning — special angle of 50°
C
CLEARANCE ANGLE
α = 7° (pos.)
Positive geometry — low cutting forces, finishing and medium machining
N
DIRECTION
Neutral (N)
Operation in both directions — neutral tool
Shank: 10×10 mm · Insert: CCMT 0602rr
Typical applications of the SCMCN 10x10 E06 turning tool
Cutting operations:
| ▸ | Longitudinal turning with facing — the 50° angle allows simultaneous cutting along the axis and facing |
| ▸ | Medium machining and finishing — positive CCMT geometry provides low cutting forces |
| ▸ | Chamfering and external tapers — angled cutting edge for chamfers and tapers |
| ▸ | Turning steps and shoulders — machining cylindrical surfaces with changes in diameter |
| ▸ | CNC production runs — quick insert replacement and repeatable positioning |
Included
Package contents for SCMCN 10x10 E06
Package contents:
| ✓ | Tool body SCMCN 10x10 E06 | 1 pcs |
| ✓ | Center screw for clamping the insert | 1 pcs |
| ✓ | Hex key for insert replacement | 1 pcs |
| ✗ | CCMT 0602rr cutting insert (sold separately) | — |
Compatible CCMT 0602rr insert
CCMT 0602rr
The cutting insert is not included in the set — must be purchased separately. CCMT insert. Positive geometry means that the insert is single-sided and has 2 cutting edges, providing low cutting forces and good surface quality.
Select the insert grade to match the workpiece material: P (structural steels), M (stainless steel), K (cast iron), N (aluminum). You can find compatible inserts in the section "Related products" below.
Insert installation and replacement for the SCMCN 10x10 E06 turning tool
Instructions for the center screw clamping system (S)
Insert replacement procedure step by step
1 Unscrew the screw
Unscrew the center screw 2-3 turns
2 Clean the insert seat
Remove chips and debris
3 Install the insert
Position in the seat
4 Tighten the screw
Torque 0.6–1.2 Nm
Important: Do not exceed the recommended tightening torque — this may damage the thread in the seat or crack the insert.
Checks before starting work:
| ▸ | Tool overhang — do not exceed 1.5× the shank height without support |
| ▸ | Cutting edge height — set the cutting edge at spindle centerline height |
| ▸ | Insert seat condition — check that the contact surface is not damaged or worn |
| ▸ | Secure clamping — the insert must have no play in the seat |
| ▸ | Indexing — when an edge wears out, rotate the insert to a fresh edge (2 edges in total) |
Note: Use coolant during machining — it extends insert life and improves surface finish. When machining without coolant, reduce the cutting parameters by 20–30%.
Frequently asked questions — SCMCN 10x10 E06
This tool accepts inserts CCMT 0602rr in any carbide grade. Select the grade to match the workpiece material: P (steels), M (stainless steel), K (cast iron), N (aluminum). You can find compatible inserts in the "Related products" section below.
The entering angle of 50° allows simultaneous longitudinal turning and facing. Suitable for machining chamfers, tapers and transitions between diameters.
The CCMT insert has positive geometry (clearance angle 7°), which means it is single-sided with 2 cutting edges. When one edge wears out, rotate the insert to a fresh edge.
