Machine Tap M10X1 DIN 371 B HSSE
Narex Zdanice spol. s r.o. Narex Zdanice spol. s r.o.
11380
€14.24 tax inc.
Net price: €11.58
Instant Shipping
In stock > 10 pcs.
Description
| Technical data | |
|---|---|
| Nominal Diameter d1 | M10x1 |
| Thread pitch P | 1,0 mm |
| Total length l1 | 90 mm |
| Length of Working Part l2 | 35 mm |
| Diameter of Grip Part d2 | 10 mm |
| Square shank size | 8 mm |
| Threaded Hole Diameter | 9.0 mm |
| B | (3-5) P |
Cutting Parameters of M10 Through Machine Threader
| ISO Symbol | Material | Cutting speed Vc [m/min] | Revolutions n [obr/min] | Feed f [obr/min] |
|---|---|---|---|---|
| P | Steel | 5-20 | 478 | 717 |
| M | Stainless steel | 5-15 | 318 | 477 |
| K | Cast iron | 5-15 | 318 | 477 |
Machine Tap through hole M10×1
Machine Tap m10×1 through -hole is a high-performance tool designed for precision cutting of fine-coil metric threads in through-holes. Made of wear-resistant HSSE high-speed steel, it guarantees durability, reliability and repeatability of machining even when working with difficult-to-cut materials such as stainless steel and alloy steels.
The tool meets the requirements of DIN 371 B, which means a medium working length design - an ideal balance between rigidity and access to deeper holes. Machine Tap The M10×1 for stainless steel provides precision threading with a fine pitch of 1 mm, conforming to ISO2 6H tolerances.
Benefits:
- HSSE steel - high resistance to wear and heat loads under harsh cutting conditions.
- M10×1 fine pitch thread - ideal for applications requiring precision and tight joints.
- DIN 371 - tool length provides an optimal balance of rigidity and accessibility.
- Effective chip evacuation - groove geometry adapted to through-holes.
- Universal application - for use in CNC machines and conventional machine tools.
Machine Tap the M10×1 through-hole is an excellent choice for professionals who expect durability, accuracy and confidence in machining fine metric threads.
