Beschreibung
Technical data of MWLNR 16x16 knife
- width of handle H - 16mm,
- height of the shank B - 16 mm,
- total length L - 100 mm,
- working height F - 20 mm,
- cutting insert - WNM. 0604
Insert clamping system - "M ".
Turning tool folding MWLNR 16x16 for longitudinal turning
Turning tool collapsibleMWLNR 16x16 06 AKKO for multi-cutting insert WNM. 0604rr. SYSTEM "M" - negative blade geometry. Double-sided replaceable inserts (the angle of application of the insert equal to 0°) are fixed with a pin on the surface of the cylindrical bore and pressure from above on the contact surface.
Knives with M-mounted inserts are the best choice for efficient machining, both roughing and finishing, requiring the highest rigidity and stability of insert clamping. The MWLNR 16x16 folding knives used are for external turning and boring of holes with large diameters (above 25 mm). The "M" system is characterized by very high repeatability of the blade position, no loose clamping elements.
* Carbide insert the cutting edge shown in the picture is not included in the lathe knife, it must be purchased separately
Product accessories
Carbide insert WNMG 060408 MA H6310 Horn
Artikel-Nr.: 12524 Auf Lager > 10 items
3,68 €
4,53 € brutto
Carbide insert WNMG 060404 MA H6310 Horn
Artikel-Nr.: 0000004428 Auf Lager > 10 items
3,68 €
4,53 € brutto
copy of Carbide insert Support AAWN-SW317 Akko
Artikel-Nr.: 14512 Auf Lager < 10 items
5,00 €
6,15 € brutto
