Beschreibung
Technical data of the planning head Fi 63 90 degrees
-working diameter D - fi 63 mm,
- number of blades Z - 5,
-diameter of the fixing hole d - 22 mm,
- height of the head L - 45 mm,
- height of blades a - 18 mm
Milling head fi 63 mm with replaceable blades
High quality milling head with a working diameter of 63 mm for planning, dedicated to TPKN inserts. This is a slip-on milling head manufactured by the Turkish company AKKO. It has the number of blades Z- 5, the diameter of the mounting hole d - 22 mm, the height of the head L - 45 mm, the height of the blade a - 18 mm and the working diameter D - fi 63 mm. AKKO milling head is suitable for side and face machining. It can be used for both roughing and medium fine machining. It is also suitable for performing finishing machining.
Offered in our store is a milling head for planning type 220.17 with diameter D-63 (AFM90C-TP22-D63-A22-Z05) dedicated to multi-cutting inserts TP.2204rr. This is the most popular type of planning heads with the designation according to the company Dolfamex. Milling heads of this type have a cutting angle of 90 degrees. They are used together with TPKN 1603 or TPKN 2204 multi-cutting inserts.
When selecting cutting inserts for our fi 63 m illing heads, the twist should be considered first. For example, if we have a right-handed milling head, we need to similarly select a right-handed multi-cutting insert for it. It is worth remembering that right-hand cutting inserts always have the letter R (from Right) in their designation, e.g. PPR, PDSR, PDTR. Nevertheless, it is also important to pay attention to the type of material you will be milling. In this case, it is necessary to choose a multi-cutting insert with the appropriate strength for the difficulty of machining. Insert designations, depending on the purpose, are always on tool packaging (P - steel, M - stainless steel, K - cast iron, N - non-ferrous alloys, aluminum, S - heat-resistant alloys, titanium alloys, H - hardened materials.)
In our offer you will find high-end milling heads 220-17, whose manufacturer is the Turkish company AKKO. It is a large professional company that has been in continuous operation since 1986. During more than forty years of activity, the company has developed an extremely innovative approach to the manufacture of cutting tools. This results in the use of the latest technologies and high-end raw materials. AKKO specializes in tool holders for CNC (Computerized Numerical Control) machine tools.
AKKO Factory is one of the largest manufacturers of folding tools for metalworking. These include milling heads, turning knives, threading tools, drills, milling cutters and many others. The company's current product range includes more than 2,500 different types of tools with a production capacity of 120,000 units per year. The company's production area is as large as 8,000 square meters. The quality of the company has been registered and confirmed by receiving the TN ES ISO 9001:2008 certificate.
The 63 mm AKKO 220-17 milling heads for planning offered in our store are made of very good materials according to the highest standards. Such execution of the heads guarantees their high quality and increased resistance to heavy cutting conditions. This allows the heads to be widely used in both small workshops and large production facilities. Their advantage is a very good quality-to-price ratio.
Product accessories
Carbide insert TPKN 1603 PDSR MTC Horn
Artikel-Nr.: 00786 Auf Lager > 10 items
3,82 €
4,69 € brutto
